Highlights
The scooter comes with a battery and a charger.
All-in-one Solid Design
The frame is made of high-strength aluminium alloy and designed in one piece with no welds, which is solid and good-looking. Thanks to the all-in-one design, KugooKirin G3 is tougher and more durable, perfect for your cross-country ride!Ā
Ā
1200W Strong Motor
The 1200W powerful motor with dual heat dissipation provides you with constant and strong power, enabling the e-scooter to speed up to 50km/h. Running with G3, your ride will be more powerful and more durable.
Ā
18Ah Large Battery
Equipped with an 18Ah large lithium-ion battery pack, KugooKirin G3 can run up to 60km on a full charge, which is definitely a great partner for your long-distance ride!
Ā
Climbing up to 30Ā°
Thanks to the strong power supply, KugooKirin G3 is able to adapt to a variety of terrains and climb an uphill slope of 30Ā°. Your cross-country ride will have more fun and excitement.
Ā
LED Touch Display
The advanced LED touch display is designed for showing various real-time data, such as speed and battery power, and also for multi-function control, which makes your ride smarter, easier and more interesting.
Ā
SPECIFICATION
Product Parameters |
|||
Model |
G3 |
||
Package |
Size |
1200*290*595MM |
|
G.W. |
31+/-1KG |
||
Basic Spec. |
Unfolded Size |
1190*1295*660MM |
|
Folded Size |
1190*550*660mm |
||
N.W. |
31+/-1KG |
||
Length of Handlebar |
660MM |
||
Height of Footboard(above the ground) |
180MM |
||
Size of Footboard |
220MM*400MM |
||
Max. Load |
120KG |
||
Waterproof Level |
IPX4 |
||
Material of Frame |
Aluminium Alloy |
||
Speed Level |
Level 1 |
25KM/H |
|
Level 2 |
35KM/H |
||
Level 3 |
50KM/H |
||
Braking System |
Front & Rear Disc Brakes + EBS |
||
Uphill |
30Ā° |
||
Max. Range |
70KM |
||
Braking Distance |
ā¤4m |
||
Max. Speed |
50KM/H |
||
Max. Idle Speed |
60KM/H |
||
Motor |
Rated Power & Voltage |
1200W, 48V |
|
Max. Instant Power |
ā„1000W (Under a limit of 25A) |
||
Max. RPM |
1000rpm |
||
Max. Output Torque |
ā„25N.m (Under a limit of 25A) |
||
Accelerating Mode |
Sine Wave |
||
Type |
One-piece Hub Motor |
||
Battery |
Capacity |
18Ah |
|
Voltage |
52V |
||
Charging Time |
8h~10h |
||
Protection System |
BMPB-509-14S-20A-02M43-0546GXX |
||
Standard Power Consumption |
936Wh |
||
Brand |
Yonglida |
||
Charger |
Input Voltage & Current |
100~240V, 3A |
|
Output Voltage & Current |
58.8V, 2A |
||
LED Headlight |
LED Qty |
2 (Left & Right) |
|
Power |
1W |
||
Beam Angle |
60Ā° |
||
Tire |
Size |
10.5" (10.5"x2.75"-6.5") |
|
Type, Material |
Pneumatic, Rubber |
||
Best Tire Pressure |
220-230kpa |
||
Brake Disc |
Outer Diameter |
140MM |
|
Thread Root Diameter |
33.3MM |
||
Display |
Type |
LED Touch Display |
|
Size |
175*52MM |
||
Content |
Speed/Battery Power/Distance/Temperature/Current/Voltage/Cruise Control/Speed Mode/Start Mode/Light Mode/Mileage Unit |
||
Function |
Activating cruise mode, removing speed limit, switching mileage/speed unit, speed mode, light mode, etc. |
||
APP |
Compatible with |
G3, MINI2 |
|
Package List |
1 x Electric Scooter, 1 x Charger |
||
Note: the max range is achieved under the following conditions: 65kg load, 25ā³CĀ temperature, at speed level 2, with no strong wind. The braking distance is achieved by dry braking at a speed of 15km/h. |
